Docker as a Service

Leverage docker to build and serve artifacts.

Docker is a powerful ecosystem which has revolutionized software development a long while ago. If we scope discussion to build pipeline, leveraging docker-based agents to offload build workload comes with a lot of advantages. Black-boxing build environments brings flexibility and scalability, but sacrifices a bit of control. It becomes harder to intervene during the build workflow. And eventually, we end up with a mixed feeling like leveraging docker is great but it will be even greater if I could build more modular pipelines mixing local processing and containerized one.

In this paper we will showcase how to address hybrid scenarios such as:

  1. I would like to offload build workload to docker but image is not the expected outcome. Instead, I would like to retrieve intermediate built artifacts to shape and ship them on my own.
  2. I would like to craft an image that involves heterogeneous content which can not be fully built sequentially by a single containerized pipeline.

Said differently, I would like to navigate back - and ideally forth - inside the docker build system.
Let’s see how one could achieve such cases.

Multi-stage builds

We use multi-stage docker build for years now. It is a very powerful tool to sequence a build pipeline while benefiting from docker caching algorithm as its best and enforcing sharpened outcome images.

Assume you are building a .NET application. You are likely to end up with a 2-stages pipeline, namely build and final below, and a COPY instruction to hand over stuff.

1
2
3
4
5
6
7

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM alpine:3.18.4 AS final

COPY --from=build xxx yyy

By doing so, we enforce final image will neither contain SDK nor intermediate build artifacts, decreasing both its size and vulnerability exposure.

Note that you can also scale this approach to combine and aggregate multiple sources. Assume you are now building a modular .NET application. You are likely to end up with a 3-stages pipeline, namely build1, build2 and final below, and multiple COPY instructions to hand over stuff.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build1

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build2

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM alpine:3.18.4 AS final

COPY --from=build1 aaa bbb
COPY --from=build2 xxx yyy

Once again, outcome image is tailored for your purpose. By splitting build in two, you also benefit from docker caching which only builds what needs to be. Last but not least, you gain paralellization for free thanks to docker dependency algorithm. As build1 and build2 are independent, they can be processed accordingly.

This approach obviously shines when you have to aggregate heterogenous content. Materializing dedicated swimlanes allows for contextual optimization.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build1

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM golang:1.21 AS build2

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM alpine:3.18.4 AS final

COPY --from=build1 aaa bbb
COPY --from=build2 xxx yyy

Multi-stage building is a docker best practice and must be applied early in your process as it greatly optimizes the overall pipeline.

Keep in mind that optimization must be propagated at the inner level as well:

  • By materializing costly steps such as dependencies fetching

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

    # -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build
WORKDIR /app

# Restore in dedicated step to benefit from cache
COPY *.csproj .
RUN dotnet restore \
    -r linux-musl-x64

# Shrink artifact
COPY . .
RUN dotnet publish \
    --no-restore \
    -o out \
    -c Release \
    -r linux-musl-x64 \
    --self-contained true \
    -p:PublishSingleFile=true \
    -p:IncludeNativeLibrariesForSelfExtract=true \
    -p:PublishTrimmed=True \
    -p:TrimMode=Link \
    /p:DebugType=None \
    /p:DebugSymbols=false

  • By leveraging tailored images

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21

    # -- -- -- -- -- -- -- -- -- -- -- -- -- --
# Start from uncluttered image..
FROM alpine:3.18.4 AS final
WORKDIR /app

# .. comes with a price
# https://learn.microsoft.com/en-us/dotnet/core/install/linux-alpine#dependencies
RUN apk add \
    bash \
    icu-libs \
    krb5-libs \
    libgcc \
    libintl \
    libssl1.1 \
    libstdc++ \
    zlib \
    --no-cache

COPY --from=build /app/out/ .

ENTRYPOINT ["./daedalus"]

Buildx engine

Buildx provides extended build capabilities through BuildKit and should be favored over plain old docker build. As they both share the same core API, switch is seamless as you only have to move from docker build to docker buildx build.

Options we are looking at in this post are:

  • The output one, which comes with different flavors, including a local type to write all result files from an image to a directory on the client side.

    1
2
3

    docker buildx build \
    --output docker_out_win \
    .

  • The target one, which provides the ability to target a specific stage and scopes build pipeline accordingly.

    1
2
3

    docker buildx build \
    --target staging \
    .

Hybrid scenarios

Artifactory

Here we would like to release not only - or not at all - our docker image but the plain old matching executables, for both windows and linux OS. Idea is still to offload build workload to a containerized pipeline, but also fetch the resulting executable artifacts to be able to upload them to artifact repository, e.g., artifactory, downstream.

We slightly amend our Dockerfile to accommodate new OS needs by leveraging built-in ARG instruction to provide OS switching. Fallback value is provided to ensure we still can build the original pipeline.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM mcr.microsoft.com/dotnet/sdk:7.0-alpine AS build

# See https://learn.microsoft.com/en-us/dotnet/core/rid-catalog
ARG dotnet_runtime=linux-musl-x64

WORKDIR /app

COPY *.csproj .
RUN dotnet restore \
    -r $dotnet_runtime

COPY . .
RUN dotnet publish \
    --no-restore \
    -o out \
    -c Release \
    -r $dotnet_runtime \
    --self-contained true \
    -p:PublishSingleFile=true \
    -p:IncludeNativeLibrariesForSelfExtract=true \
    -p:PublishTrimmed=True \
    -p:TrimMode=Link \
    /p:DebugType=None \
    /p:DebugSymbols=false

And we now have the ability to provide specific value from the buildx command line through build-arg option.

1
2
3

docker buildx build \
    --build-arg dotnet_runtime=linux-x64 \
    .

This in place we introduce an extra stage to perform the artifact extraction. We took the opportunity to use scratch image to do so.

1
2
3
4

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM scratch as staging

COPY --from=build /app/out/* .

Here we simply grab generated executable from the build stage and populate staging stage with.

Once prerequisites are now set up, we can trigger the desired pipelines from the command line.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

# Generate win-x64 executable and fetch it back to local drive in docker_out_win folder
docker buildx build \
    --target staging \
    --build-arg dotnet_runtime=win-x64 \
    --output docker_out_win \
    .

# Generate linux-x64 executable and fetch it back to local drive in docker_out_linux folder
docker buildx build \
    --target staging \
    --build-arg dotnet_runtime=linux-x64 \
    --output docker_out_linux \
    .

So now we have full-access to our so-desired executables, we can unfold downstream pipeline, eg upload them to artifactory through JFrog CLI.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

export OUTPUT_PATH='./docker_out_linux'
export ARTIFACTORY_PATH='Path/to/daedalus'
export GITHUB_SHA=$(git rev-parse HEAD)
export DOTNET_RUNTIME='linux-x64'

jf rt upload \
    --detailed-summary \
    --flat=true \
    --target-props="build.sourceversion=$GITHUB_SHA" \
    $OUTPUT_PATH/* \
    $ARTIFACTORY_PATH/$USERNAME/$DOTNET_RUNTIME/

One could argue we could have wrapped JFrog CLI within a container as well and stay in docker ecosystem the whole path along. That is right. But sometimes we do not have choice or we have simplest ones. Here, as the build pipeline is intented to be unfold within a GitHub workflow, we would like to leverage existing JFrog GitHub Actions to deal with artifactory publishing.

WASM

Assume now we would like to explore WASM ecosystem and decide to build and deploy a .NET application. .NET ecosystem provides a useful Wasi.Sdk nuget package to easily enrich build pipeline with this new platform. On the other side, docker ecosystem has been enriched to deal with WASM workload, via brand-new platform and runtime parameters.

This in mind, we craft a 2-stages Dockerfile:

  • build generates the WASM version of the .NET executable.
    As we only have to leverage Wasi.Sdk nuget, we can start from a plain old mcr.microsoft.com/dotnet/sdk image
  • final uses WASM artifact to feed the final image through COPY instruction
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

FROM mcr.microsoft.com/dotnet/sdk:7.0 AS build
WORKDIR /app

# To please Wasi.Sdk nuget
RUN apt-get update \
    && apt-get install \
    libxml2-dev \
    -yq --no-install-suggests --no-install-recommends \
    && apt-get clean \
    && rm -rf /var/lib/apt/lists/*

COPY *.csproj ./
RUN dotnet restore

COPY . ./
RUN dotnet build -c Release -o out

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM scratch as final

COPY --from=build /app/out/HelloWasm.wasm .

ENTRYPOINT [ "/HelloWasm.wasm" ]

Once done we can trigger pipeline through buildx, specifying the WASM platform we are targetting for.

1
2
3
4
5

docker buildx build \
    --platform wasi/wasm \
    --provenance=false \
    -t hellowasm  \
    .

And it miserably fails..

1

ERROR: failed to solve: mcr.microsoft.com/dotnet/sdk:7.0: no match for platform in manifest

In fact, buildx engine applies platform option to the whole pipeline which fails as we do not have a matching WASM version of mcr.microsoft.com/dotnet/sdk. To fix this, we have to chunk pipeline, triggering first half with default platform and second half with WASM one. But we also have to hand over artifact from one stage to the other. Here it is not only being able to navigate back from docker ecosystem but being able to navigate forth as well.

Let’s reshape our Dockerfile to accommodate our new needs by adding a brand-new staging stage, acting as a middle-man to articulate our chunks.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

FROM mcr.microsoft.com/dotnet/sdk:7.0 AS build
WORKDIR /app

RUN apt-get update \
    && apt-get install \
    libxml2-dev \
    -yq --no-install-suggests --no-install-recommends \
    && apt-get clean \
    && rm -rf /var/lib/apt/lists/*

COPY *.csproj ./
RUN dotnet restore

COPY . ./
RUN dotnet build -c Release -o out

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM scratch as staging

COPY --from=build /app/out/HelloWasm.wasm .

# -- -- -- -- -- -- -- -- -- -- -- -- -- --
FROM scratch as final

COPY ./docker_out/HelloWasm.wasm /HelloWasm.wasm

ENTRYPOINT [ "/HelloWasm.wasm" ]

Our pipeline in place, we can sequence pipeline by chaining two buildx calls.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

# Generate WASM artifact and fetch it back to local drive in docker_out folder
docker buildx build \
    --target staging \
    --output docker_out \
    .

# Generate WASM image by fetching WASM artifact from local drive
docker buildx build \
    --target final \
    --platform wasi/wasm  \
    --provenance=false \
    -t hellowasm  \
    .

Obviously, you can check that our WASM image is a valid one by exercising through different runtime.

1
2
3
4
5
6
7
8
9

docker run --rm \
    --runtime=io.containerd.wasmedge.v1 \
    --platform=wasi/wasm \
    hellowasm

docker run --rm \
    --runtime=io.containerd.wasmtime.v1 \
    --platform=wasi/wasm \
    hellowasm

Closing

Docker ecosystem is backed up by great tooling. When exploring this ecosystem one can find new ways to deal with tricky problems. It is not only to use the right tool for the job but to learn how to combine tools to shape new one. We showcase here that we can combine both multi-stage and buildx features to smooth boundaries between local world and containerized one and enable back and forth navigation. It does not mean we have to move towards this hybrid facility every time. It only means that if we have to, we now know how to operate. And that’s already great. At least for today.
